Product Overview
9840 (CT9840FC-3) Installation and User’s Guide for the NonStop S-Series Enclosure— 524959-003
1 -9
NonStop S-series Tape Enclosure
NonStop S-series Tape Enclosure
The Nonstop S-series enclosures can be purchased as a base enclosure or a
stackable enclosure. The enclosures come without a door, so drives are easily
accessed. An ESD rear cover is provided to cover the wiring and cables. All
units are configured for NonStop
S-Series servers and are designed to fit the
5157 tape drive, 5157 ACL tape drive, 5257 tape drive, 5257 ACL tape drive,
CT9840-3 tape drive, and the CT9840FC-3 tape drive.
Dimensions
For an illustration of the dimensions, see Figure 1-3 on page 1-10.
Table 1-6. Tape Enclosure Dimensions
Dimension Description Measurements
Height Enclosure 37.6 inches
Caster 1.75 inches
Drive space 8 inches
Width Front and back side 22 inches
Drive space 17.50 inches
Depth Outside of
enclosure 32 inches
