HP UPS Management Module web interface 65
SNMP Managers tab
This screen enables administrators to enter information for SNMP managers. SNMP managers are
computers that use the HP Power MIB to request information from the management module.
To configure SNMP managers:
1. Enable the SNMP manager configuration for up to five servers.
2. Enter the IP address for each SNMP manager in the IP Address field.
NOTE: SNMP managers cannot communicate with the management module until the IP
address is entered on the SNMP Managers screen.
3. Enter the Read community string for each SNMP manager.
4. Enter the Write community string for each SNMP manager.
5. Configure the access type for each SNMP manager.
o RO—Read Only
o RW—Read/Write
6. Do one of the following:
o Click Save Settings to save the information.
o Click Undo Changes to undo the changes.
o Click Help to view online help.
