Lsmutil example, Using lsmutil with logical server storage, Lsmutil storage options – HP Matrix Operating Environment Software User Manual
Page 94: Using lsmutil, With logical server storage

Table 7-1 LSMUTIL options (continued)
Description
Parameters
Option
Preallocate initiator WWNs for a specified Virtual Connect Domain
Group. Displays the reserved WWNs to standard output in ASCII format.
You must specify a Virtual Connect Domain Group name and an integer
from 1 to 100. If an invalid domain group is specified, the available
domain groups are displayed.
DomainGroupName
number of WWNs
--reserveWWNs
Displays the current version of the logical servers tables in the Insight
Dynamics database to standard output.
--version
Lists the valid options for the LSMUTIL script. This is the default option
if no option is specified.
--help
LSMUTIL example
C:\> LSMUTIL --list
Server and storage list on host pvm1 at 2010-10-18 16:00:20
Server Name Type Arch State Storage WWN
cBlade Blade Integ NEW 50:06:0B:00:05:02:00:ab
jsh-s8921392_Integrity Blade Integ INACTIVE 50:00:1F:E1:50:03:50:69
jshIntegrityBlade1 Blade Integ NEW 50:06:0B:00:05:02:00:2E
jshVcLinux1 Blade ProLnt NEW 50:06:0B:00:05:02:00:31
jshWinLS1 Blade ProLnt NEW 50:06:0B:00:05:02:00:39
jy-integ-vc1 Blade Integ NEW 50:06:0B:00:05:02:00:2E
ML VC RHEL SAN BOOT Blade ProLnt ACTIVE 50:00:1F:E1:50:03:50:69
ssvc1 Blade Integ NEW 50:06:0B:00:05:02:00:2C
use7224lvn_ls Blade ProLnt ACTIVE 50:06:0B:00:05:02:00:09
use7234m2y_ls_jshLinux Blade ProLnt ACTIVE 50:06:0B:00:05:02:00:2F
Storage Name State WWN
cBlade_lss_258 USED 50:06:0B:00:05:02:00:ab
C:\>
Using LSMUTIL with logical server storage
The LSMUTIL command line interface can be used to:
•
Modify storage information to create multiple storage pool entries without using the logical
server storage screens in Virtualization Manager (see
“Creating multiple storage pool entries”
)
•
Facilitate communication between the server administrator who defines storage pool entries,
and the storage administrator who creates, presents, and zones storage (see
communication between server and storage administrators”
•
Request initiator WWNs for storage preallocation
“Requesting server (initiator) WWNs for
•
Modify server information to include details about local disks (see
servers with local disk information”
Table 7-2 LSMUTIL storage options
Purpose
LSMUTIL option
Export storage pool entries into an XML file, which can be modified and
then imported
NOTE: This option cannot be used with catalog-based storage pool entries
--exportSPE
•
Import modified storage pool entries from an XML file
•
Create multiple storage pool entries by importing pre-allocated storage
volumes from an XML file
NOTE: This option cannot be used with catalog-based storage pool entries
--importSPE
94
LSMUTIL database utility
