Page 51

Features and Functions
2
U2761A User’s Guide
33
Remote Interface Operation
VOLTage
Or, you can set the amplitude by specifying a high level and
low level using the following commands.
VOLTage:HIGH
VOLTage:LOW
You can also use the APPLy command to select the function,
frequency, amplitude, and offset.
DC Offset Voltage
The default offset is 0 V for all functions.
Limits Due to Amplitude
The relation between the offset voltage and output amplitude
is shown below. Vmax is the maximum peak voltage for the
selected output termination (5 V for a 50
Ω load or 10 V for
a high
-impedance load).
If the specified offset voltage is not valid, the U2761A will
automatically adjusts it to the maximum DC voltage allowed
with the specified amplitude.
V
offset
V
max
V
pp
2
---------
–
≤
