Page 104

86
U2761A User’s Guide
2
Features and Functions
Remote Interface Operation
TRIGger:SOURce {IMMediate|EXTernal|BUS}
Internal Triggering
In the Internal trigger mode, the U2761A continuously
performs frequency sweep (as specified by the sweep time).
This is the default trigger source for both soft front panel
and remote interface use.
Soft Front Panel Operation
On the Trigger Setup panel as shown in
, select
Internal from the drop down list
at the Source
panel.
Remote Interface Operation
TRIGger:SOURce IMMediate
Manual Triggering
In the Manual (software) triggering mode, you can manually
trigger the U2761A by clicking
Trigger .
The
U2761A
initiates one sweep each time you click the button. The
Trigger
button is illuminated while the U2761A waits
for a Manual trigger.
Soft Front Panel Operation
On the Trigger Setup panel as shown in
, select
Manual from the drop down list
at the Source
panel.
