Replacing a backplane, Avaya m770 backplanes – Avaya M770 User Manual
Page 29
Chapter 4
Replacing Components
Avaya M770 User’s Guide
19
Replacing a Backplane
The Avaya M770 has two backplanes. The lower backplane serves the X-switch and
Avaya M440 Gate Switch modules, while the upper backplane connects the
Avaya M770 ATM modules. Each backplane is sent with a detailed Installation
Guide. The location of each backplane in the hub is shown in Figure 4.2 below.
Figure 4.2
Avaya M770 Backplanes
