Chapter 3
Signals and Pinout Tables
38
Reference Manual
COM 830
C-D Connector Signal Descriptions
A4
3
USB2+ B43
USB3+ A98
VCC_12V
B98
TV_DAC_
B
A4
4
USB_2_3_OC# B44
USB_0_1_OC# A99
VCC_12V B99
TV_DAC_
C
A4
5
USB0-
B45 USB1-
A10
0
GND (FIXED)
B10
0
GND
(FIXED)
A4
6
USB0+ B46
USB1+ A10
1
VCC_12V B10
1
VCC_12V
A4
7
VCC_RTC B47
EXCD1_PERST#
A10
2
VCC_12V B10
2
VCC_12V
A4
8
EXCD0_PERST# B48
EXCD1_CPPE#
A10
3
VCC_12V B10
3
VCC_12V
A4
9
EXCD0_CPPE# B49
SYS_RESET#
A10
4
VCC_12V B10
4
VCC_12V
A5
0
LPC_SERIRQ
B50 CB_RESET#
A10
5
VCC_12V B10
5
VCC_12V
A5
1
GND (FIXED)
B51
GND (FIXED)
A10
6
VCC_12V B10
6
VCC_12V
A5
2
PCIE_TX5+ B52
PCIE_RX5+ A10
7
VCC_12V B10
7
VCC_12V
A5
3
PCIE_TX5- B53
PCIE_RX5- A10
8
VCC_12V B10
8
VCC_12V
A5
4
GPI0 B54
GPO1 A10
9
VCC_12V B10
9
VCC_12V
A5
5
PCIE_TX4+ B55
PCIE_RX4+ A11
0
GND (FIXED)
B11
0
GND
(FIXED)
NOTE
The signals marked with an asterisk symbol (*) are not supported on the COM 830.
PCIE_TX5± and PCIE_RX5± are used for the onboard Gigabit Ethernet and
therefore are not available.
Table 3-17. PCI Signal Descriptions
Signal
Description
I/O
PU/PD
Comment
PCI_AD[0:31]
PCI bus multiplexed address and data lines
I/O
3.3V
PCI_C/BE[0:3]# PCI bus byte enable lines, active low
I/O
3.3V
PCI_DEVSEL#
PCI bus Device Select, active low
I/O
3.3V
PU 8k2
3.3V
PCI_FRAME#
PCI bus Frame control line, active low
I/O
3.3V
PU 8k2
3.3V
PCI_IRDY#
PCI bus Initiator Ready control line, active
low
I/O
3.3V
PU 8k2
3.3V
Table 3-16. Connector A-B Pinout (Continued)
