Chapter 3
Signals and Pinout Tables
COM 830
Reference Manual
35
SUS_S3#
Indicates system is in Suspend to RAM state.
Active low output. Also known as "PS_ON"
and can be used to control an ATX power
supply.
O 3.3VSB
PU 10k
3.3VSB
SUS_S4#
Indicates system is in Suspend to Disk state.
Active low output.
O 3.3VSB
PU 10k
3.3VSB
Not
supported
SUS_S5#
Indicates system is in Soft Off state.
O 3.3VSB
PU 10k
3.3VSB
WAKE0#
PCI Express wake up signal.
I 3.3VSB
PU 10k
3.3VSB
WAKE1#
General purpose wake up signal. May be used
to implement wake-up on PS/2 keyboard or
mouse activity.
I 3.3VSB
PU 10k
3.3VSB
BATLOW#
Battery low input. This signal may be driven
low by external circuitry to signal that the
system battery is low, or may be used to signal
some other external power-management event.
I 3.3VSB
PU 10k
3.3VSB
THRM#
Input from off-module temp sensor indicating
an over-temp situation.
I 3.3V
PU 10k
3.3V
THERMTRIP
#
Active low output indicating that the CPU has
entered thermal shutdown.
O 3.3V
PU 10k
3.3V
SMB_CK
System Management Bus bidirectional clock
line. Power sourced through 5V standby rail
and main power rails.
I/O
3.3VSB
PU 2k2
3.3VSB
SMB_DAT#
System Management Bus bidirectional data
line. Power sourced through 5V standby rail
and main power rails.
I/O
3.3VSB
PU 2k2
3.3VSB
SMB_ALERT
#
System Management Bus Alert – active low
input can be used to generate an SMI# (System
Management Interrupt) or to wake the system.
Power sourced through 5V standby rail and
main power rails.
I 3.3VSB
PU 10k
3.3VSB
Table 3-15. Power and GND Signal Descriptions
Signal
Description
I/O
PU/
PD
Comment
VCC_12V
Primary power input: +12V nominal. All
available VCC_12V pins on the connector(s)
shall be used.
P
VCC_5V_SBY
Standby power input: +5.0V nominal. If
VCC5_SBY is used, all available
VCC_5V_SBY pins on the connector(s) shall
be used. Only used for standby and suspend
functions. May be left unconnected if these
functions are not used in the system design.
P
Table 3-14. Power and System Management Signal Descriptions (Continued)
