PIN FUNCTION DESCRIPTIONS
Pin Name Function
OUTPUTS
HSOUT
Horizontal Sync Output
A reconstructed and phase-aligned version of the Hsync input. Both the polarity and duration of this output can be
programmed via serial bus registers. By maintaining alignment with DATACK, and Data, data timing with respect
to horizontal sync can always be determined.
VSOUT Vertical Sync Output
A reconstructed and phase-aligned version of the video Vsync. The polarity of this output can be controlled via a
serial bus bit. The placement and duration in all modes is set by the graphics transmitter.
SOGOUT Sync-On-Green Slicer Output
This pin outputs either the signal from the Sync-on-Green slicer comparator or an unprocessed but delayed version
of the Hsync input. See the Sync Processing Block Diagram (Figure 12) to view how this pin is connected.
(Note: Besides slicing off SOG, the output from this pin gets no other additional processing on the AD9883A.
Vsync separation is performed via the sync separator.)
SERIAL PORT
(Two-Wire)
SDA
Serial Port Data I/O
SCL Serial Port Data Clock
A0 Serial Port Address Input 1
For a full description of the two-wire serial register and how it works, refer to the Two-Wire Serial Control Port section.
DATA OUTPUTS
RED
Data Output, RED Channel
GREEN Data Output, GREEN Channel
BLUE Data Output, BLUE Channel
The main data outputs. Bit 7 is the MSB. The delay from pixel sampling time to output is fixed. When the sampling
time is changed by adjusting the PHASE register, the output timing is shifted as well. The DATACK and HSOUT
outputs are also moved, so the timing relationship among the signals is maintained. For exact timing information, refer
to Figures 7 and 8.
DATA CLOCK OUTPUT
DATACK
Data Output Clock
This is the main clock output signal used to strobe the output data and HSOUT into external logic. It is produced by
the internal clock generator and is synchronous with the internal pixel sampling clock. When the sampling time is
changed by adjusting the PHASE register, the output timing is shifted as well. The Data, DATACK, and HSOUT
outputs are all moved, so the timing relationship among the signals is maintained.
INPUTS
R
AIN
Analog Input for RED Channel
G
AIN
Analog Input for GREEN Channel
B
AIN
Analog Input for BLUE Channel
High-impedance inputs that accept the RED, GREEN, and BLUE channel graphics signals, respectively. (The
three channels are identical, and can be used for any colors, but colors are assigned for convenient reference.) They
accommodate input signals ranging from 0.5 V to 1.0 V full scale. Signals should be ac-coupled to these pins to
support clamp operation.
HSYNC Horizontal Sync Input
This input receives a logic signal that establishes the horizontal timing reference and provides the frequency
reference for pixel clock generation. The logic sense of this pin is controlled by serial register 0Eh Bit 6 (Hsync
Polarity). Only the leading edge of Hsync is active, the trailing edge is ignored. When Hsync Polarity = 0, the falling
edge of Hsync is used. When Hsync Polarity = 1, the rising edge is active. The input includes a Schmitt trigger
for noise immunity, with a nominal input threshold of 1.5 V.
VSYNC Vertical Sync Input
This is the input for vertical sync.
SOGIN Sync-on-Green Input
This input is provided to assist with processing signals with embedded sync, typically on the GREEN channel. The pin
is connected to a high-speed comparator with an internally generated threshold. The threshold level can be programmed
in 10 mV steps to any voltage between 10 mV and 330 mV above the negative peak of the input signal. The default voltage
threshold is 150 mV. When connected to an ac-coupled graphics signal with embedded sync, it will produce a
noninverting digital output on SOGOUT. (This is usually a composite sync signal, containing both vertical and horizontal sync
information that must be separated before passing the horizontal sync signal to Hsync.) When not used, this input should be left
unconnected. For more details on this function and how it should be configured, refer to the Syncon-Green section.
