13 7-0 Post-Coast
This register allows the coast signal to be applied follow-
ing to the Vsync signal. This is necessary in cases where
post-equalization pulses are present. The step size for this
control is one Hsync period.
The default is 0.
14 7 Hsync Detect
This bit is used to indicate when activity is detected on
the Hsync input pin (Pin 30). If Hsync is held high or
low, activity will not be detected.
Table XXVII. Hsync Detection Results
Detect Function
0 No Activity Detected
1 Activity Detected
The sync processing block diagram shows where this
function is implemented.
14 6 AHS – Active Hsync
This bit indicates which Hsync input source is being used
by the PLL (Hsync input or Sync-on-Green). Bits 7 and 1
in this register are what determine which source is used. If
both Hsync and SOG are detected, the user can determine
which has priority via Bit 3 in register 0EH. The user can
override this function via Bit 4 in register 0EH. If the
override bit is set to Logic 1, then this bit will be forced to
whatever the state of Bit 3 in register 0EH is set to.
Table XXVIII. Active Hsync Results
Bit 7 Bit 1 Bit 4, Reg
(Hsync (SOG 0EH
Detect) Detect) (Override) AHS
0 0 0 Bit 3 in 0EH
0 1 0 1
1 0 0 0
1 1 0 Bit 3 in 0EH
X X 1 Bit 3 in 0EH
AHS = 0 means use the Hsync pin input for Hsync.
AHS = 1 means use the SOG pin input for Hsync.
The override bit is in register 0EH, Bit 4.
14 5 Detected Hsync Input Polarity Status
This bit reports the status of the Hsync input polarity
detection circuit. It can be used to determine the polarity
of the Hsync input. The detection circuit’s location is
shown in the Sync Processing Block Diagram (Figure 12).
Table XXIX. Detected Hsync Input Polarity Status
Hsync Polarity Status Result
0 Hsync Polarity Is Negative
1 Hsync Polarity Is Positive
14 4 Vsync Detect
This bit is used to indicate when activity is detected on
the Vsync input pin (Pin 31). If Vsync is held high or low,
activity will not be detected.
Table XXX. Vsync Detection Results
Detect Function
0 No Activity Detected
1 Activity Detected
The Sync Processing Block Diagram (Figure 12) shows
where this function is implemented.
14 3 AVS – Active Vsync
This bit indicates which Vsync source is being used; the
Vsync input or output from the sync separator. Bit 4 in this
register determines which is active. If both Vsync and
SOG are detected, the user can determine which has
priority via Bit 0 in register 0EH. The user can override this
function via Bit 1 in register 0EH. If the override bit is set
to Logic 1, this bit will be forced to whatever the state of Bit 0
in register 0EH is set.
Table XXXI. Active Vsync Results
Bit 5
(Vsync Detect)
Override AVS
0 0 0
1 0 1
X 1 Bit 0 in 0EH
AVS = 0 means Vsync input.
AVS = 1 means Sync separator.
The override bit is in register 0EH, Bit 1.
14 2 Detected Vsync Output Polarity Status
This bit reports the status of the Vsync output polarity
detection circuit. It can be used to determine the polarity
of the Vsync output. The detection circuit’s location is
shown in the Sync Processing Block Diagram.
Table XXXII. Detected Vsync Output Polarity Status
Vsync Polarity Status Result
0 Vsync Polarity Is Active Low
1 Vsync Polarity Is Active High
14 1 Sync-on-Green Detect
This bit is used to indicate when sync activity is detected
on the Sync-on-Green input pin (Pin 49).
Table XXXIII. Sync-on-Green Detection Results
Detect Function
0 No Activity Detected
1 Activity Detected
The sync processing block diagram shows where this
function is implemented.
14 0 Detected COAST Polarity Status
This bit reports the status of the coast input polarity
detection circuit. It can be used to determine the polarity
of the coast input. The detection circuit’s location is shown
in the Sync Processing Block Diagram (Figure 12).
