REV. 0 –3–
AD9883A
Test AD9883AKST-110 AD9883AKST-140
Parameter Temp Level Min Typ Max Min Typ Max Unit
DIGITAL OUTPUTS
Output Voltage, High (V
OH
) Full VI V
D
– 0.1 V
D
– 0.1 V
Output Voltage, Low (V
OL
) Full VI 0.1 0.1 V
Duty Cycle DATACK Full IV 45 50 55 45 50 55 %
Output Coding Binary Binary
POWER SUPPLY
V
D
Supply Voltage Full IV 3.0 3.3 3.6 3.15 3.3 3.6 V
V
DD
Supply Voltage Full IV 2.2 3.3 3.6 2.2 3.3 3.6 V
P
VD
Supply Voltage Full IV 3.0 3.3 3.6 3.0 3.3 3.6 V
I
D
Supply Current (V
D
) 25
°C
V 132 180 mA
I
DD
Supply Current (V
DD
) 2 25
°C
V 19 26 mA
IP
VD
Supply Current (P
VD
) 25
°C
V 8 11 mA
Total Power Dissipation Full VI 525 650 650 800 mW
Power-Down Supply Current Full VI 5 10 5 10 mA
Power-Down Dissipation Full VI 16.5 33 16.5 33 mW
DYNAMIC PERFORMANCE
Analog Bandwidth, Full Power 25
°C
V 300 300 MHz
Transient Response 25
°C
V 2 2 ns
Overvoltage Recovery Time 25
°C
V 1.5 1.5 ns
Signal-to-Noise Ratio (SNR) 25 °C V 44 43 dB
(Without Harmonics) Full V 43 42 dB
f
IN
= 40.7 MHz
Crosstalk Full V 55 55 dBc
THERMAL CHARACTERISTICS
θ
JC
Junction-to-Case
Thermal Resistance V 16 16
°C/W
θ
JA
Junction-to-Ambient
Thermal Resistance V 35 35
°C/W
NOTES
1 VCO Range = 10, Charge Pump Current = 110, PLL Divider = 1693.
2 DATACK Load = 15 pF, Data Load = 5 pF.
Specifications subject to change without notice.
