0F 4 Coast Input Polarity Override
This register is used to override the internal circuitry that
determines the polarity of the coast signal going into
the PLL.
Table XX. Coast Input Polarity Override Settings
Override Bit Result
0 Coast Polarity Determined by Chip
1 Coast Polarity Determined by User
The default for coast polarity override is 0.
0F 3 Coast Input Polarity
A bit to indicate the polarity of the COAST signal that is
applied to the PLL COAST input.
Table XXI. Coast Input Polarity Settings
Coast Polarity Function
0 Active LOW
1 Active HIGH
Active LOW means that the clock generator will ignore
Hsync inputs when COAST is LOW, and continue
operating at the same nominal frequency until COAST
goes HIGH.
Active HIGH means that the clock generator will ignore
Hsync inputs when COAST is HIGH, and continue
operating at the same nominal frequency until COAST
goes LOW.
This function needs to be used along with the COAST
polarity override bit (Bit 4).
The power-up default value is 1.
0F 2 Seek Mode Override
This bit is used to either allow or disallow the low-power
mode. The low-power mode (seek mode) occurs when
there are no signals on any of the Sync inputs.
Table XXII. Seek Mode Override Settings
Select Result
1 Allow Seek Mode
0 Disallow Seek Mode
The default for this register is 1.
0F 1 PWRDN
This bit is used to put the chip in full power-down. See
the section on power management for details of which
blocks are actually powered down.
Table XXIII. Power-Down Settings
Select Result
0 Power-Down
1 Normal Operation
The default for this register is 1.
10 7-3 Sync-on-Green Slicer Threshold
This register allows the comparator threshold of the Sync-
on-Green slicer to be adjusted. This register adjusts it in
steps of 10 mV, with the minimum setting equaling 10 mV
(11111) and the maximum setting equaling 330 mV (00000).
The default setting is 23 and corresponds to a threshold
value of 0.15 V.
10 2 Red Clamp Select
A bit that determines whether the RED channel is clamped
to ground or to midscale. For RGB video, all three
channels are referenced to ground. For YcbCr (or YUV),
the Y channel is referenced to ground, but the CbCr
channels are referenced to midscale. Clamping to midscale
actually clamps to Pin 37.
Table XXIV. Red Clamp Select Settings
Clamp Function
0 Clamp to Ground
1 Clamp to Midscale (Pin 37)
The default setting for this register is 0.
10 1 Green Clamp Select
A bit that determines whether the GREEN channel is
clamped to ground or to midscale.
Table XXV. Green Clamp Select Settings
Clamp Function
0 Clamp to Ground
1 Clamp to Midscale (Pin 37)
The default setting for this register is 0.
10 0 Blue Clamp Select
A bit that determines whether the BLUE channel is
clamped to ground or to midscale.
Table XXVI. Blue Clamp Select Settings
Clamp Function
0 Clamp to Ground
1 Clamp to Midscale (Pin 37)
The default setting for this register is 0.
11 7:0 Sync Separator Threshold
This register is used to set the responsiveness of the sync
separator. It sets how many internal 5 MHz clock periods
the sync separator must count to before toggling high or
low. It works like a low-pass filter to ignore Hsync pulses
in order to extract the Vsync signal. This register should
be set to some number greater than the maximum Hsync
pulsewidth. Note: the sync separator threshold uses an
internal dedicated clock with a frequency of approxi-
mately 5 MHz.
The default for this register is 32.
12 7-0 Pre-Coast
This register allows the coast signal to be applied prior to
the Vsync signal. This is necessary in cases where pre-
equalization pulses are present. The step size for this
control is one Hsync period.
The default is 0.
