Table VI. Control Register Map (continued)
Write and
Hex Read or Default Register
Address Read Only Bits Value Name Function
15H R/ W 7:0 Test Register Bits [7:2] Reserved for future use.
Bit 1 – 4:2:2 Output Formatting Mode.
Bit 0 – Must be set to 0 for proper operation.
16H R/ W 7:0 Test Register Reserved for future use.
17H RO 7:0 Test Register Reserved for future use.
18H RO 7:0 Test Register Reserved for future use.
NOTE
1 The AD9883A only updates the PLL divide ratio when the LSBs are written to (register 02h).
TWO-WIRE SERIAL CONTROL REGISTER DETAIL
CHIP IDENTIFICATION
00
7–0 Chip Revision
An 8-bit register which represents the silicon revision.
Revision 0 = 0000 0000, Revision 1 = 0000 0001,
Revision 2 = 0000 0010.
PLL DIVIDER CONTROL
01
7–0 PLL Divide Ratio MSBs
The eight most significant bits of the 12-bit PLL divide ratio
PLLDIV. (The operational divide ratio is PLLDIV + 1.)
The PLL derives a master clock from an incoming Hsync
signal. The master clock frequency is then divided by an
integer value, such that the output is phase-locked to
Hsync. This PLLDIV value determines the number of
pixel times (pixels plus horizontal blanking overhead) per
line. This is typically 20% to 30% more than the number
of active pixels in the display.
The 12-bit value of the PLL divider supports divide ratios
from 2 to 4095. The higher the value loaded in this regis-
ter, the higher the resulting clock frequency with respect
to a fixed Hsync frequency.
VESA has established some standard timing specifications,
which will assist in determining the value for PLLDIV as
a function of horizontal and vertical display resolution and
frame rate (Table V).
However, many computer systems do not conform pre-
cisely to the recommendations, and these numbers should
be used only as a guide. The display system manufacturer
should provide automatic or manual means for optimizing
PLLDIV. An incorrectly set PLLDIV will usually produce
one or more vertical noise bars on the display. The greater
the error, the greater the number of bars produced.
The power-up default value of PLLDIV is 1693
(PLLDIVM = 69h, PLLDIVL = Dxh).
The AD9883A updates the full divide ratio only when the
LSBs are changed. Writing to the MSB by itself will not
trigger an update.
02 7–4 PLL Divide Ratio LSBs
The four least significant bits of the 12-bit PLL divide ratio
PLLDIV. The operational divide ratio is PLLDIV + 1.
The power-up default value of PLLDIV is 1693
(PLLDIVM = 69h, PLLDIVL = Dxh).
The AD9883A updates the full divide ratio only when this
register is written to.
CLOCK GENERATOR CONTROL
03
7–6 VCO Range Select
Two bits that establish the operating range of the clock
generator.
VCORNGE must be set to correspond with the desired
operating frequency (incoming pixel rate).
The PLL gives the best jitter performance at high fre-
quencies. For this reason, in order to output low pixel
rates and still get good jitter performance, the PLL actu-
ally operates at a higher frequency but then divides down
the clock rate afterwards. Table VII shows the pixel rates
for each VCO range setting. The PLL output divisor is
automatically selected with the VCO range setting.
Table VII. VCO Ranges
VCORNGE Pixel Rate Range
00 12–36
01 36–72
10 72–110
10 110–140
The power-up default value is 01.
03 5–3 CURRENT Charge Pump Current
Three bits that establish the current driving the loop filter
in the clock generator.
Table VIII. Charge Pump Currents
CURRENT Current (
␮A)
000 50
001 100
010 150
011 250
100 350
101 500
110 750
111 1500
CURRENT must be set to correspond with the desired
operating frequency (incoming pixel rate).
The power-up default value is CURRENT = 001.
