Wireless LAN 802.11b/g Device
9
2 Antenna Attachment
This chapter contains instructions for antenna installation.
Important
It is assumed that there is an existing wireless LAN network with an internet connection that has
been set up on your computer prior to using the Software Access Point. Please consult your ISP for
further information.
If you have already attached the antenna to your HP PC, please skip to Chapter 3.
1. Screw the antenna connector (A) to the antenna jack (B) located on the back of the HP PC.
OR
Figure 1: Antenna Attachment
2. Place the HP PC on a table or place the antenna in an elevated and open area to achieve the
best wireless performance.
1 1 A
B
A
B
