■ Outputting Audio to Speakers
It is possible to output audio from the projected images to AV equipment or
amplified speakers.
Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor
will reduce the audio volume.
To AUDIO OUT
terminal
Audio cable (not included)
RCA terminal
Mini jack
AUDIO IN terminal
(AUDIO IN)
Projector
Speaker
