Connection Procedure
137
Inst
alla
tio
n
an
d Main
te
nan
ce
Inst
allation
Connecting AV Equipment
Connect the projector and AV equipment.
The description provided here is one example. For more detailed information, refer
to the manual for the connected AV equipment.
■ Connecting to Digital Video Output Terminal (Digital
Connection)
Connecting with an HDMI cable (Input signal type: [HDMI]
Before connecting the cables, turn off both the projector and AV equipment.
Digital video camera
Digital video
output terminal
(HDMI Terminal)
HDMI cable (not included)
* When an HDMI cable is connected,
digital audio is also connected at the
same time.
To HDMI terminal
AV equipment
Projector
