Control panel overview, 7" touchscreen lcd and touchpanel – Brother MFC-J6920DW User Manual
Page 20

Chapter 1
6
Control panel overview
1
3.7" Touchscreen LCD and Touchpanel
1
This is a Touchscreen LCD with an electrostatic Touchpanel that only shows the LEDs that can
be used.
1 3.7" Touchscreen LCD (Liquid Crystal
Display)
This is a Touchscreen LCD. You can access
the menus and options by pressing them as
they are displayed on this screen.
You can adjust the angle of the Touchscreen
LCD and Touchpanel by lifting it. To lower this
control panel, push the release button that is
located behind the control panel, as shown in
the illustration.
2
1
