Selecting frame patterns
*
Frame patterns are created by combining the
desired frame and type of stitch.
Example
1. Touch “ ”.
*
If another type of pattern such as characters
or if a memory card has been inserted, press
“CHARACTERS & DESIGNS” first and then
touch “ ”.
2. Select the desired shape for the frame.
1
If you touch “NEXT”, additional frame shapes
will be displayed. (There are a total of 10
different frame shapes available.)
3. Select the desired type of stitch to form the
frame.
2
If you touch “NEXT”, additional stitch types
will be displayed. (There are a total of 12
different stitch types available.)
4. The combined pattern is then shown on the
LCD screen.
3
Screen A – The operation of each key shown
on this screen is described on the following
page.
35
1
2
3
