5. installing the dk roll – Brother QL-570VM User Manual
Page 23

23
Getting started
2
2-5. Installing the DK Roll
1.
Press and hold the ON/OFF button to turn the QL-570 off. Hold
the DK Roll compartment cover at the front of the Brother QL-
570 and firmly lift up to open the cover.
2.
Put the spool into the spool guides in the DK Roll compartment.
NOTE
• Make sure that the spool arms are inserted firmly in the spool guides on
the left and right.
• Insert the spool into the machine as shown in the illustration.
