7
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 800285 1 Gray Main Door Assembly Complete
(includes illus. nos. 1,5,6 and 7)
2 800448 1 12 1/2" Stainless Steel Main Door Hinge Assembly
3 150410 4 # 10-24 X 3/8" Phillips Pan Head Taptite Screw
4 152014 4 1/4-20 Free Spin Wash Nut
5 102353 1 69 1/2" Main Door Gasket
6 102210 1 20 7/16" Door Glass
170730 1 Glass Adhesive for Lightweight (plastic) Main Door Assembly
(10.3 oz cartridge)
7 150431 1 Main Door Latch Screw (#10 x 7/16" Dome Hex Head Screw)
Main Door Assembly
