ARM Cortex R4F User Manual
Page 395
Cycle Timings and Interlock Behavior
ARM DDI 0363E
Copyright © 2009 ARM Limited. All rights reserved.
14-31
ID013010
Non-Confidential, Unrestricted Access
First address not 64-bit aligned
VLDM{mode}.32
1
1
1
1
-
VLDM{mode}.32
2
2
1,2
2
-
VLDM{mode}.32
2
3
1,2,2
3
-
VLDM{mode}.32
3
3
1,2,2,3
3
-
VLDM{mode}.64
2
2
2
2
-
VLDM{mode}.64
3
3
2,3
3
-
VLDM{mode}.64
4
4
2,3,4
4
-
VLDM{mode}.64
5
5
2,3,4,5
5
-
Table 14-25 Floating-point load/store instructions cycle timing behavior (continued)
Example instruction
Cycles/
memory
cycles
Cycles with
writeback (!)
Result
latency
(load)
Result
latency
(base
register,
Comments
