Introduction
ARM DDI 0363E
Copyright © 2009 ARM Limited. All rights reserved.
1-15
ID013010
Non-Confidential, Unrestricted Access
Table 1-2 describes the various features that can be pin-configured to be either enabled or
disabled at reset. It also shows which CP15 register field provides software configuration of the
feature when the processor is out of reset. All of these fields exist in either the system control
register, or one of the auxiliary control registers.
BTCM at reset
Disabled
-
Pin
Enabled
Base address configured
Base address
0x0
Pin and build
Peripheral ID
RevAnd field
Any 4-bit value
-
Build
AXI slave
interface
No AXI-slave
-
Build
AXI-slave included
-
TCM Hard Error
Cache
No TCM Hard Error Cache
-
Build
TCM Hard Error Cache
included
c
-
Non-Maskable
FIQ Interrupt
Disabled (FIQ can be
masked by software
-
Pin
Enabled
-
Parity type
d
Odd parity
-
Pin
Even parity
-
a. Only available with the Cortex-R4F processor.
b. Only if the relevant TCM port(s) are included.
c. Only if at least one TCM port is included and uses ECC error checking.
d. Only relevant if at least one TCM port is included and uses parity error checking, one of the caches includes parity checking,
or AXI or TCM bus parity is included.
Table 1-1 Configurable options (continued)
Feature
Options
Sub-options
Build-configuration
or pin-configuration
Table 1-2 Configurable options at reset
Feature
Options
Register
Exception endianness
Little-endian/big-endian data for exception handling
EE
Exception state
ARM/Thumb state for exception handling
TE
Exception vector table
Base address for exception vectors:
0x00000000
/
0xFFFF0000
V
TCM error checking
ATCM parity check enable
a
ATCMPCEN
BTCM parity check enable, for B0TCM and B1TCM independently
B0TCMPCEN/
B1TCMPCEN
ATCM ECC check enable
ATCMPCEN
BTCM ECC check enabled, for B0TCM and B1TCM together
B0TCMPCEN/
B1TCMPCEN
