Cycle Timings and Interlock Behavior
ARM DDI 0363E Copyright © 2009 ARM Limited. All rights reserved. 14-13
ID013010 Non-Confidential, Unrestricted Access
Note
Result Latency is one less if the result is used as the accumulate value for a subsequent multiply
accumulate. This only applies if the result is the same width as the accumulate value, that is 32
or 64 bits.
SMLALD , SMLALDX 1 , - 2, 2
SMLSLD
,
SMLSLDX
1
,
- 2, 2
UMAAL 2 , , 3, 3
Table 14-9 Example multiply instruction cycle timing behavior (continued)
Example
instruction
Cycles Early Reg Late Reg Result latency
