ESC/P Command Reference
- 7 -
2. Examples of Using ESC/P Commands
Step 2: Specify the page length.
*The page length does not include the margins.
For the margins, subtract 6 mm (48 dots) from the page length.
nL nH mL mH
ESC ( C 02h 00h FCh 02h
Entered command
4 inches=812 dots
812 dots– 48 dots =764 dots
Page length=mL+mH*256=764
==
2
02h
==
252
FCh
ESC (C Specify page length
ASCII: ESC ( C nL nH mL mH
Decimal: 27 40 67 nL nH mL mH
Hexadecimal: 1B 28 43 nL nH mL mH
Parameters
nL=2, nH=0
0≤（mL+mH*256）<8192
Description
 Specifies the page length.
* A page length 0 indicates the Auto setting.
 The unit is 1/203 inch (=1 dot).
Page length=mL+mH*256
 The current paper position is the TOF.
 The top and bottom margins are canceled with ESC ( c.
 All previously entered text is cleared.
 A standard unit is not used.
 This command is available only with continuous length tape.
4 inches
At your side
Step 3: Specify the horizontal position.
1 inch=203 dots
Horizontal position=n1+n2*256=203
ESC $ CBh 00h
nL nH Entered command = =
203
CBh
0
00h
= =
At your side
1 inch
