ESC/P Command Reference
- 70 -
5. Control Command Details
(4) [Backslash]: End of barcode
Barcode Type Command
POSTNET, UPC/EAN EXTENTION, CODE39,
ITF(I-2/5), EAN-8, EAN-13, UPC-A, UPC-E,
CODABAR, RSS symbols
ESC i [Parameter] B or b [Barcode data] \
CODE93, CODE128,
GS1-128 (UCC/EAN-128)
ESC i [Parameter] B or b [Barcode data] \\\
Description
 Specifies a barcode image.
 Any data extending beyond the right margin is ignored.
 Since the check digit is generated automatically from the barcode data, the check digit is not sent as
barcode data. Since the length of the barcode data is also checked, the data would not be correctly
recognized if the check digit data was present.
 With CODE39, ITF (I-2/5), CODABAR, CODE128, GS1-128 (UCC/EAN-128) or RSS Expanded, the buffer
length for the barcode image is about 22 cm. A barcode longer than 22 cm will not be printed.
 The characters that can be printed with CODE128 and GS1-128 (UCC/EAN-128) are the 128 ASCII
characters and the special codes FNC1, FNC2, FNC3 and FNC4.
Codes assigned to the special codes:
FNC1: 86h, FNC2: 81h, FNC3: 80h, FNC4: 84h
 The control codes and special codes appear as spaces when characters are printed below CODE128 and
GS1-128 (UCC/EAN-128) barcodes.
 The control codes appear as spaces when characters are printed below CODE93 barcodes.
 Special code FNC1 can also be printed with RSS Expanded.
This special code also appears as a space when characters are printed below the barcode.
Code assigned to the special code:
FNC1: 86h
 The width can be set to extra extra small only with CODE128 and EAN128.
 Characters are not printed below the barcode when the width is set to extra extra small.
Example
For barcode type CODE39, with no characters printed below the barcode, a size of large (width) × 480 dots
(height) and a ratio between thick and thin bars of 3:1, the command will be as shown below.
ESC i t0 r0 he0h 01h w3 z0 B 123456789 \
