ESC/P Command Reference
- 55 -
5. Control Command Details
ESC (C Specify page length
ASCII: ESC ( C nL nH mL mH
Decimal: 27 40 67 nL nH mL mH
Hexadecimal: 1B 28 43 nL nH mL mH
Parameters
nL=2, nH=0
0<(mL+mH*256)<12000
Description
 Specifies the page length.
 The unit is 1/300 inch (=1 dot).
Page length=mL+mH*256
 The current paper position is the TOF.
 The top and bottom margins are canceled with ESC ( c.
 All previously entered text is cleared.
 A standard unit is not used.
 This command is available only with continuous length tape.
Inch, mm, and dot conversion table
inch mm Number of dots
0 0.0 0
1 25.4 300
2 50.8 600
3 76.2 900
4 101.6 1200
5 127.0 1500
6 152.4 1800
7 177.8 2100
8 203.2 2400
9 228.6 2700
10 254.0 3000
11 279.4 3300
12 304.8 3600
13 330.2 3900
14 355.6 4200
15 381.0 4500
16 406.4 4800
17 431.8 5100
18 457.2 5400
19 482.6 5700
20 508.0 6000
