Brother RJ-4030 - Manual (Page 18)

Raster Command Reference
- 14 -
2. Print Data
2.3.3 Feed amount
The feed amount (left and right margins) is defined below.
Type Minimum Margin Setting Maximum Margin Setting
Continuous length tape
3 mm
0.12"
24 dots 127 mm
5"
1020 dots
Die-cut labels
The length offset indicated in “(b) Die-cut labels” of “ 2.3.2 Page size ”
is used.
However, set
“0” as the value of the “specify margin amount”
command.
2.3.4 Maximum and minimum lengths
The maximum and minimum lengths are defined below.
Type Minimum Length Maximum Length
Device Capabilities
Value of DC_MINEXTENT 25.4 mm
204 dots 3000 mm
24094 dots
Continuous length tape
25.4 mm
204 dots 3000 mm
24094 dots
Die-cut labels Fixed Fixed
