Raster Command Reference
- 13 -
2. Print Data
(b) Die-cut labels
Print area
1
6
2
5
3
4
Number 1 Width 2 Length
3 Print area width (maximum printing width) 4 Print area length
5 Width offset 6 Length offset
ID Label Size 1 2 3 4 5 6
423
RD 102 mm x 26 mm
RD 4" x 1"
101.6 mm
812 dots
25.6 mm
195 dots
98.6 mm
788 dots
20.5 mm
156 dots
1.5 mm
12 dots
3.0 mm
24 dots
419
RD 102 mm x 50 mm
RD 4" x 2"
101.6 mm
812 dots
49.9 mm
399 dots
98.6 mm
788 dots
43.9 mm
351 dots
1.5 mm
12 dots
3.0 mm
24 dots
424
RD 102 mm x 76 mm
RD 4" x 3"
101.6 mm
812 dots
76.2 mm
609 dots
98.6 mm
788 dots
70.2 mm
561 dots
1.5 mm
12 dots
3.0 mm
24 dots
425
RD 102 mm x 102 mm
RD 4" x 4"
101.6 mm
812 dots
101.6 mm
812 dots
98.6 mm
788 dots
95.6 mm
764 dots
1.5 mm
12 dots
3.0 mm
24 dots
420
RD 102 mm x 152 mm
RD 4" x 6"
101.6 mm
812 dots
152.4 mm
1218dots
98.6 mm
788 dots
140.5 mm
1123 dots
1.5 mm
12 dots
6.0 mm
48 dots
