Raster Command Reference

- 11 -

2. Print Data

Descriptions for the numbers in the print data on the previous page are provided in the following table.

For details on each command, refer to “

4. Printing Command Details

”.

No.

Command Name

Description

Invalidate

A 350-byte invalidate command is sent.

2

Initialize

The “initialize” command is sent.

3

Switch dynamic
command mode

The printer is switched to raster mode.
Send this command before sending raster data to the printer.

4

Additional media
information command

Additional media information on the media size is sent.
This is the command for “4" × 6" (102 mm × 152 mm)”.

5

Print information
command

Media size information for the print data is sent.
This is the command for “4" × 6" (102 mm × 152 mm)” die-cut
labels.

6

Various mode settings

(1Bh+69h+4Dh+00H)

This is the command for specifying settings such as cut options.
Since there are no cut options with this model, it is unnecessary
to send this command.

7

Specify margin amount

Since a margin amount cannot be specified with die-cut labels,
this command is sent with a margin amount of 0.

8

Select compression
mode

TIFF compression mode is selected.

9

Raster data

Raster data continues.

10

Print command with
feeding

Since one page will be printed, this is sent at the end of the first
page.
