HOSE REEL-OPTIONAL
86037390 09/06/07
5-52
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86191620
56-501962
1
REEL, VACUUM HOSE GRAY
2
86177270
03-000124
2
CLAMP, MFLR 1-3/4
3
86175990
52-501685
2
BUSHING, HOSE REEL
4
86174560
56-501960
1
BASE, HOSE RL (250’)
5
86175740
56-502207
1
BRKT, LOCKOUT HOSE REEL
6
86186870
61-950854 1 LATCH
ASSEMBLY
7
86270330
02-000066 2 FLATWASHER,
1/4
8
86010780
87162
2
WASHER, 1/4 SLPIT LOCK
9
86274750
70270
2
SCR, 1/4-20 X 3/4 HHCS PLTD
10
86005650
57031 2
NUT,
5/16-18
HEX
11
86191820
56-501968
1
REEL, HP HOSE GRAY
12
86174740
45-802138 2 BEARING
HOSE
REEL
13
86278830
02-000143 4 FLATWASHER,
5/16
14
86279130
87083
4
WASHER, 5/16 SPLIT LOCK PLTD
15
86006750
70302
4
SCR, 5/16-18 X 1” HHCSGR5PLT
16
86181030
44-802122 4 FLANGE,
47MST
17
86174730
56-501961
1
BODY, HP HOSE GRAY
18
86277830
00-000072
10 SCR, 3/8-16 X 2” HXHD
19
86190170
50-500511
1
PLATE, INSTALL MT
20
86279510
87171 10
WASHER,
3/8
FLAT
21
86005770
57119
10 NUT, 3/8-16 HEX NYLOCK
22
86189850
55-501789
1
PIN, LOCK HOSE REEL
23
86175700
50-501812
1
BRKT, HOSE REEL LOCK
24
86193240
04-000302
1
SPRING, LOCK-LOCK PIN ASSY
25
86177190
04-000303
1
CLIP, RETAINER-LOCK PIN ASSY
