WAND-TITANIUM SIX JET-OPTIONAL
86037390 02/14/07
5-32
REF
PART NO.
PRV NO.
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86273310
00-000282 SCR, CAP 1/4-20 X 1 1/4 SOC
2
86192030
00-000317 SCR, CAP 10-32 X 1 1/4 SOCH
3
86006680
70228
SCR, 10-32 X 1/4 PPHMS SS
4
86270990
57090
NUT, 10-32 HEX NYLOCK SS
5
86264910
04-000093 TIE, CABLE 13”
6 - OPEN
-
7
86184270
10-805504 HOSE, 3/16 X 44-1/2
8
86247680
56015
NIPPLE, 1/4 HEX
9
86190180
11-800206 PLUG, 1/8 SOCHD BR
10
86177650
12-800060 CONN, 1/4P X 1/4T BR
11
86177710
12-800322 CONN, 1/8P X 1/4T COMP BR
12
86005580
56012
NIPPLE, 1/4 FPT QD
13
86193490
14-806512 STRAINER, JET 50 MESH
14
86194450
17-803018 TIP, SPRAY 9501 X 1/8P SST
15
86195570
17-803006 WASHER, NYLON
16
86177860
17-803010 CONN, 1/4P X 11/16-16M
17
86177870
17-803036 CONN, 1/4FP X 11/16-16F BR
18
86194580
17-803078 TIP, SPRAY 8001 SST 1/8 VJET
19
86194650
52-501619 TRIGGER, WD VALVE
20
86174680 52-502008BK BODY, WD HDL, 2” TB, BK
21
86198180
52-502009 HOLD DN-WD HDL 2” TUBE
22
86187610
52-502057 MANFOLD, LEFT
23
86187620
52-502058 MANIFOLD, RIGHT
24
86174060
56-502548 ASSY, MNFLD S-BEND
25
86288810
56-502534 WD BDY, TITAN HD W/SST TUBE
26
86174120
61-950496 ASSY, EXTRACTOR VALVE
27
86193360
16-808189 STEM, EXTRACTOR VALVE
28
86193200
16-808190 SPRING, EXTRACTOR VALVE
29 86192410 16-808228
SEAT, EXTRACTOR VALVE
30
86183160
16-808229 HLDR, VLV STEM-EXTRACTOR VL
31
86189510
43-810062 O-RING, .114 ID .254OD
32
86189520
43-810063 O-RING, .551ID .691OD
33
86174500
43-810064 BACK-UP, .250DIA
34
86174630
52-501590 BDY, EXTRACTOR VLV
35
86179250
48-941462 DEC, WD HD TITANIUM
