WAND- TRI JET-OPTIONAL
86037390 02/14/07
5-36
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM NOTES:
- 86285520 89233 WAND, TJW (9502) PC COMPLETE
- 86285510 89232 WAND, TJW, (95015) CUBXL COMPLETE
- 86285530 89234 WAND, TJW, (9503) PC COMPLETE
1 86005580 56012 NIPPLE, 1/4 FPT QD
2 86177860 17-803010 CONN, 1/4P X 11/16-16M
3 86195570 17-803006 WASHER, NYLON
4 86193490 14-806512 STRAINER, JET 50MESH
5 86177870 17-803036 CONN, 1/4FP,11/16-16R BR
6 86247680 56015 NIPPLE, 1/4 HEX
7 86280020 09-805359 SLEEVE, WD HDL 9.5
8 86194650 52-501619 TRIGGER, WD VLV
9 86192030 00-000317 SCR, CAP 10-32X 1-1/4 SOCH
10 86270990 57090 NUT, 10-32 HEX NYLOCK SS
11 86174120 61-950496 ASSY, EXTRCTR VLV
12 86177650 12-800060 CONN, 1/4P X 1/4T BR
13 86183970 10-805253 HOSE, 3/16X49 (1/8P X 1/4FT)
14 86265730 04-000053 TIE, CABLE 8” WHT
15 86273310 00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
16 86198160 52-501569 HOLD DOWN, WD HDL
17 86182840 791150 BODY, WD HDL
18 - OPEN -
19 86194410 17-803002 TIP, SPRY 9502X1/8P SST 89233
19A 86194400 17-803001 TIP, SPRY 9501X1/8P SST 89232
19B 86194520 17-803046 TIP, SPRY 9503X1/8P SST 89234
20 86274290 70162 SCR, 10-32 X 3/8 PPHMS SS
21 86279470 87165 WASHER, #10 SPLIT LOCK
22 86270800 57014 NUT, 10-32 HEX SS
23 86187700 56-501739 MANIFOLD, WD TRI-JET
24 86190180 11-800206 PLUG, 1/8 SOCHD BR
25 86183160 16-808229 HOLDER, VLV STEM-EXTRCTR VL
26 86189520 43-810063 O-RING, .551 ID .691 OD
27 86192410 16-808228 SEAT, EXTRCTR VLV
28 86193360 16-808189 STEM, EXTRCT VLV
29 86174500 43-810064 BACK-UP, .250DIA
30 86189510 43-810062 O-RING, .114ID .254OD
31 86193200 16-808190 SPRING, EXTRCTR VLV
32 86179020 52-501590 BODY, EXTRCTR VLV
- 86179020 48-941166 DECAL, WD HD NOT SHOWN
- 86186160 66-808169 KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS
25-27 & 29-31
