Water pump & chemical pump – Prochem Blazer XL User Manual
Page 51
WATER PUMP & CHEMICAL PUMP
86037390 08/21/07
5-12
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86177320 03-000249
1
CLMP, CABL 1/4ID 3/8BLT
2
86177020 03-000113
1
CLAMP, HOSE #12 SST
3
86181370 12-800278
1
FTTG, BRB 1/2P X 3/4H BR
4
86180230 11-800299
1
ELL, STREET 1/2 45 DEG
5
86180410 12-800225
1
ELL, 3/8P X 1/2T BR
6
86190670 41-809153
1
PMP, WTR CAT 3CP1140
7
86180340 12-800031
1
ELL, 1/4P X 1/4T BR
8
86190520 11-800224
1
PLUG, 3/8 SOCHD BR
9 86190990
44-802312 1
BELT, AX32 GOODYEAR MATCH
10 86191070
44-802252 1 PULL,
1TA40
11
86273440 00-000340
3
SCR, MACH 5/16-18 X 1” GR8
12 86049240
54-500680 1 KEY, 3/16 SW X 7/8
13
86137310
87098
1
WASHER, M8 SPLIT LOCK
14 86190540
12-800029 1 PLUG,
1/4T
BR
15
86276130
70601
2
SCR, 5/16-1/8 X 2.75 HHCS GR5
16
86278830 02-000143
2
WASHER, 5/16 FLAT PLTD
17
86005750
57113
2
NUT, 5/16-18 HEX NYLOCK
18
86006740
70266
4
SCR, 3/8-16 X 1” HHCSGR5PLT
19
86010790
87163
5
WASHER, 3/8 SPLIT LOCK
20
86279510
87171
4
WASHER, 3/8 FLAT
21
86042550
790869
1
BRKT, WTR PMP ADJ
22 86185370
52-501925 1 HUB,
PUMP
WATER
23
86273420 00-000336
1
SCR, CAP 3/8-16 X 3 ALL THD
24
86180360 12-800040
1
ELL, 1/8P X 1/4T BR
25
86191440
791173
1
PUMP, CHEM, PULSE, GP
1000151479 WAS 41-809158
26
86179920
790605
1
EL, 90DEG 1/8 X 5/16HB
27
86173750 52-809125
1
ADPT, CAT CHEM PUMP
28
86191780 52-809123
1
RETAIN, VALVE SPRING
29
86274650
70254
1
SCR, M8 X 18 SHCS PLTD
30
86194630
65250
1
PULSE PUMP, TOP COVER INLET
1000151479 WAS 52-502053
31
86179550 42-809047
1
DIAPHRAGM, CHEM PUMP
32 86249220 65252 1 PLASTIC
DISC
1000151479 WAS 42-809264
33
86173440 43-810105
1
O-RING, 1-58 ID X 1-3/4 OD VITON
1000151479
34
86195100
65245
1
VALVE CAP, 303 SST, INPUT
1000151479 WAS 16-808237
35
86195110
65247
2
VALVE KIT, ASM, CHEM, PULSE PUMP 1000151479 WAS 42-809265
36
86189290
65249
2
O-RING, DURO, .862ID X .103CS
1000151479 WAS 43-810079
37
86191340
65253
1
PULSE PUMP, BODY
1000151479 WAS 52-502052
38
86192920
65246
1
SPACER RING, 303 SST
1000151479
39
86195120
65248
1
VALVE CAP, 303 SST, OUTPUT
1000151479 WAS 16-808237
