UPHOLSTERY TOOL-OPTIONAL
86037390 01/25/08
5-40
REF
PART NO.
PRV NO.
QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
-
86285260
78513
1
TL, UPHOLST, PC (80015)
COMPLETE
1
86280240
09-805131
2
HOSE, VAC 1-1/4X10’ BLU
2
86178660
08-805243
1
CUFF,
SWIV
1-1/4HX1-1/4T
3
86184670
10-805347
1
HOSE, 3/16X119-1/2 (1/8PX1/4FT)
4
86179720
13-806023
1
DSC, 1/8FC1/8FP SST
5
86178550
58-500639
1
UPHOLSTERY TL TRIGGER
6
86273370
00-000310
1
SCR, CAP 4-40 X7/32 SHCS SS
7
86193050
04-000282
1
SPRING, VAC ADJ BUTT
8
86176080
52-501624
1
BUTTON, VAC ADJ
9
86194590
52-501842
1
TOOL,
UPHOLSTERY
10
86174140
61-950570
1
ASSY, UPHLST TL VLV
INCLUDES PARTS
20-26, 28, & 31- 37
11
86005580
56012
1 NIPPLE,
1/4
NPT
QD
12
86177860
17-803010
1 CONN,
1/4P
X
11/16-16M
13
86195570
17-803006
1 WASHER,
NYLON
14
86193490
14-806512
1 STRAIRNER,
JET
50MESH
15
86177870
17-803036
1 CONN,
1/4FPX11/16-16F
BR
16
86188320
11-800404
1 NIP,
1/4X5
SST
17
86178520
52-501585
1 COUPLER,
UPHLST
TL
-
86178480
52-501655
1
CPLG, UPHLST TL HOS
NOT SHOWN
18
86177660
12-800065
1 CONN,
1/8P
X
1/4T
19
86178630
08-805138
1
CUFF, 1 1/4H X 1 1/2T GRY
20
86183160
16-808229
1
HOLDER, VLV STEM-EXTRCTR VL
21
86189520
43-810063
1
O-RING, .551 ID .691 OD
22
86192410
16-808228
1 SEAT,
EXTRCTR
VLV
23
86193360
16-808189
1 STEM,
EXTRCTR
VLV
24
86174500
43-810064
1 BACK-UP,
250DIA
25
86189510
43-810062
1
O-RING, .144 ID .254 OD
26
86189510
16-808190
1 SPRING,
EXTRCTR
VLV
27
86273350
00-000306
2
SCR, 6-32 X 1 SCHD SS
28
86194500
17-803033
1
TIP, SPRY 80015X1/8P SST
29
86178540
58-500638
1 CSTG,
TRIGGER
CLMP
30
86273360
00-000307
2
SCR, CAP 6-32X3/8 SOCHD
31
86195210
52-501623
1 VALVE,
UPHLST
TL
32
86195530
52-501626
1
VALVE, ADJ-UPHLST TL VLV
33
86189460
43-810016
1 O-RING,
5/32IDX9/32OD
VIT
34
86182570
43-807513
1
GASKET, UPHLST TL VLV
35
86183770
10-805348
1
HOSE, 3/16X6-1/2 (1/8P BS)
36
86179740
13-806030
1
D SC, 1/8MX1/8FP SST
37
86192070
00-000408
1
SCR, SET 3-32 X 1/4 SOCHD
-
86178980
48-941164
1 DECAL,
UPHLST
TL
NOT SHOWN
- 86186160
66-808169 1 KIT,
REPAIR-WAND
VLV
NOT SHOWN
INCLUDES PARTS
20-22 & 24-26
