HEAT EXCHANGER
86037390 02/14/07
5-16
REF PART
NO. PRV
NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86056820
790714
3
SPACER, ENG SUPPORT
2 86278830
02-000143
9
WASHER, 5/16 FLAT PLTD
3 86192110
790721
3
SCR, 5/16-18 X 4.0 HHMS PLATED
4 86274750
70270
26
SCR, 1/4-20 X 3/4 HHCS PLTD
5 86010780
87162
24
WASHER, 1/4 SPLIT LOCK PLTD
6 86270330
02-000066
24
FLATWASHER, 1/4
7 86029430
790707
1
MUFFLER, VAC W/EXH TUBE
8 86181810
43-807080
1
GASKET, VAC HE INLET
9
86177000 03-000086
1
CLAMP, MFLR 1-1/4
10
86059020
790708
1
TUBE, SILENCER/EXH MNFLD
11 86051550
790578
1
PLT, BLNK CVR, VAC HE
12 86047250
790668
1
COVER, SST CORE VAC HE
13
86049190
790671
1
HSG, VAC HE
14 86177700
12-800282
2
CONN, 3/8P X 1/2T BR
15 86180220
11-800276
3
ELL, 3/8 BR
16 86181400
12-800345
2
FTTG, BRB 3/8P X 5/8H BR
17 86182190
36238
6
GROMT, 1/2ID C 1-1/4OD 1/8G 5/16W
18 86190520
11-800224
6
PLUG, 3/8 SOCHD BR
19
86187210
790038
3
MANIFOLD, HEATER CORE
20
86047260
790680
1
COVER, COP CORE VAC HE
21 OPEN
-
-
22
86030280
790801
1
ASSY, HEATER CORE COPPER
INCLUDES 17 & 20
23
86189730
790423
4
PAD, REAR VAC HTR CORE
24
86181850
790050
3
GASKET, VAC HE CVR
25
86005650
57031
3
NUT, 5/16-18 HEX
26
86279130
87083
6
WASHER, 5/16 SPLIT LOCK PLTD
27
86275760
70540
3
SCR, 5/16-18 X 1 HHCS GR8 PLTD
28
86181330 12-800161
1
FTTG, BRB 3/8P X 1/2H BR
29
86043150
790388
1
ASSEMBLY, HEATER CORE SS
30
86010740
87090
2
WASHER, 1/4 ID X 3/4 OD PLTD
