Prochem Blazer XL - Manual (Page 77)

STAIR TOOL-OPTIONAL
86037390 01/25/08
5-38
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM NOTES:
- 86285350 78519 TL, STAIR, LNG, TM DJ (80015) COMPLETE
- 86285290 78521 TL, STAIR, SHT, TM (80015) COMPLETE
1 - OPEN -
2 86198080 52-501576 BODY, WD HDL PORT
3 86198170 52-501577 HOLD DOWN, WD HDL PORT
4 86265730 04-000053 TIE, CABLE 8” WHT
5A 86183710 10-805330 HOSE, 3/16X14.5 (1/8PX1/4)
5B 86184000 10-805397 HOSE, 3/16X7-1/2 (1/8P X 1/4F)
6 86194410 17-803002 TIP, SPRY 9502X1/8P SST
7 86273310 00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
8 86177650 12-800060 CONN, 1/4P X 1/4T BR
9 86192030 00-000317 SCR, CAP 10-32X1-1/4 SOCH
10 86270990 57090 NUT, 10-32 HEX NYLOCK SS
11 86174120 61-950496 ASSY, EXTRCTR VLV
12 86247680 56015 NIPPLE, 1/4 HEX
13 86005580 56012 NIPPLE, 1/4 FPT QD
14 86194650 52-501619 TRIGGER, WD VLV
15A 86280020 09-805359 SLEEVE, WD HDL 9.5
15B 86040950 09-805504 SLEEVE, STAIR TL HDL 7-1/8
16 86183160 16-808229 HOLDER, VLV STEM-EXTRCTR VL
17 86189520 43-810063 O-RING, .551 ID .691 OD
18 86192410 16-808228 SEAT, EXTRCTR VLV
19 86193360 16-808189 STEM, EXTRCTR VLV
20 86174500 43-810064 BACK-UP, .250DIA
21 86189510 43-810062 O-RING, .114 ID .254 OD
22 86193200 16-808190 SPRING, EXTRCTR VLV
23 86174630 52-501590 BODY, EXTRCTR VLV
- 86178970 48-941163 DECAL, STAIR TL NOT SHOWN
- 86186160 66-808169 KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS
16-19 & 20-22
