WATER BOX
86037390 12/12/08
5-20
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86273410
00-000335
4
SCR, 1/4-20 X 8 HXHD
2 86010780
87162
4
WASHER, 1/4 SPLIT LOCK PLTD
3 86270330
02-000066
2
FLATWASHER, 1/4
4 86048360
50-501763
1
HOLD DOWN WTR BOX
5 86187820
58-500781
1
MOLDING, WATER BOX
6 86174540
19-807014
1
BALL, FLOAT
7 86177660
12-800065
1
CONN, 1/8P X 1/4T
8 86195340
15-808075
1
VLV, TEMP REL 145 DEG
9 86058750
790696
1
TRAY, WTR BX
10 86181150
54-501715
1
FLOAT ROD
11 86181370
12-800278
1
FTTG, BRB 1/2P X 3/4H BR
12 86180230
11-800299
1
ELL, STREET 1/2 45 DEG
13 86274750
70270
4
SCR, 1/4-20 X 3/4 HHCS PLTD
14 86188180
11-800300
2
NIP, 1/2 X CL
15 86193440
14-806540
2
STRAINER, SUC END 1/2FP
16 86272720
11-800345
1
PLUG, 1/4 SOCHD BRASS
17 86270770
57006
2
NUT, 1/4-20 HEX
18 86177060
03-000246
2
CLAMP, HOSE #8 SST
19 86181360
12-800269
2
FTTG, BRB 1/2P X 5/8H BR
20 86180570
31098
1
ELL, STREET 1/2 BR
21 86177260
03-000111
2
CLMP, HOSE #10 9/16 MIN
22 86180250
11-800361
1
ELL, 1/2 BR
23 86195060
15-808110
1
VALVE, FLOAT
24 86046550
11-800432
1
CAP, WATER BOX
25 86189010
52-501706
1
NUT, FLOAT VALVE
26
86309160
-
1
BDY, FLOAT VALVE
WAS 16-808217
27
86308950
-
1
SCR, HHSS, M5 X 20MM, SS
WAS 00-000337
28
86309140
-
1
ARM, PIVOT-FH VALVE
WAS 16-808216
29 86189870
16-808219 1 PISTON,
FH
VLV
30
86192380 16-808164
1
SEAT, FLOAT VLV
31
86024750
94028
1
NUT, M5 HEX NYLOCK SS
WAS 57090
