Control panel-upper – Prochem Blazer XL User Manual
Page 45
CONTROL PANEL-UPPER
86037390 01/25/08
5-6
REF PART
NO. PRV
NO. QTY
DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86195050 15-808106
1
VALVE, METER 1/8FP
2
86177660 12-800065
2
CONN, 1/8P X 1/4T
3
86247720
56032
1
NIPPLE, 1/8 CLOSE
4 86136310 57086 4
NUT,
M5
HEX
5
86297070
-
1
VALVE, 3-WAY BALL 1/8P
6
86180140 11-800014
1
ELL, STREET 1/8 BR
7
86181300 12-800093
3
FTTG, BRB 1/8P X 5/16H
8
86270920
57049
4
NUT, 6-32 HEX NYLOCK SS
9
86274290
70162
4
SCR, 10-32 X 3/8 PPHMS SS
10
86279470
87165
4
WASHER, #10 SPLIT LOCK PLTD
11
86180380 12-800101
1
ELL, 1/4FP X 1/4 POLY BR
12
86180350 12-800035
1
ELL, 1/4FP X 1/4T BR
13
86190830
791061
1
PNL, FRNT, BLZR XL, PC
14
86246890
54092
1
METER, 0-60VDC HOUR
15 86270330
02-000066 4 FLATWASHER,
1/4
16
86010780
87162
4
WASHER, 1/4 SPLIT LOCK PLTD
17
86274750
70270
4
SCR, 1/4-20 X 3/4 HHCS PLTD
18
86175680
140702
2
BRKT, WIKA MOUNTING
19 86175500
33-900162 1 BREAKER, CIRCUIT, 25A
20 86175490
33-900161 1 BREAKER, CIRCUIT, 30A
21 86186020
32-900174 1 KEYSWITCH
22 86193760
32-900206 1 SW,
RTRY W/BYPASS NON-ILL
23
86181930
36225
1
GAUGE, 0-1500 PSI
24
86181950
36227
1
GAUGE, VACUUM 30” HG
25
86262870
791082
1
LABEL, CONTROL PNL, BLZR XL
26
86186620
500834
1
LABEL, CHEM PNL XL
27 86181170
18-808513 1 FLOWMETER,
1/8FP
28 86176120
49-802518 1 CABLE,
CHOKE
29
86177540
791081
1
CNTRL, THRTL, BLZRXL, CLR/CLNR
30
86186650
500838
1
LABEL, FRNT HD, BXL, PC
31
86255920
73811
2
STANDOFF, 3-32 X 1/2 HEX NYL
32
86191740 35-900188
1
RELAY, ENG SHUTDOWN
33
86017360
140675
1
BRKT, FLOW METER
