4 Commissioning - ATEX
BU 0240 GB
29
4.2.2.3
Hand-held Technology Units for ATEX Zone 22 3D
All hand-held technology units are not approved for continuous use in the ATEX Zone 22 3D. The may
therefore only be used during commissioning or for maintenance purposes, if it is ensured that no explosive
dust atmosphere exists.
Name
Part Number
Approved for
ATEX Zone 22 3D
Not approved for
ATEX Zone 22 3D
SK CSX-3H
275281013
x
SK PAR-3H
275281014
x
ATTENTION
The diagnostic opening of the basic unit for the connection of a hand-held
technology unit or a PC must not be opened in an atmosphere containing
explosive dust.
4.2.2.4 Braking
resistors
External braking resistors of type SK BRE4-x-xxx-xxx are not permitted for use in ATEX Zone 22 3D.
Name
Part Number
Approved for
ATEX Zone 22 3D
Not approved for
ATEX Zone 22 3D
SK BRI4-1-100-100
275272005
x
SK BRI4-1-200-100
275272008
x
SK BRI4-1-400-100
275272012
x
SK BRI4-2-100-200
275272105
x
SK BRI4-2-200-200
275272108
x
SK BRE4-1-100-100
275273005
x
SK BRE4-1-200-100
275273008
x
SK BRE4-1-400-100
275273012
x
SK BRE4-2-100-200
275273105
x
SK BRE4-2-200-200
275273108
x
ATTENTION
If an internal braking resistor of type SK BRI4-x-xxx-xxx is used, the power limitation for
this must be activated under all circumstances. This is usually done by setting DIP
switch 8 to "ON". Alternatively, parameters (P555), (P556) and (P557) can be
parameterised with the appropriate values. Only the resistors assigned to the relevant
inverter type may be used.
