Millivolt per Volt Calibration Menu Structure

To enter the

MilliVolt per Volt Calibration Menu, press and hold the

and

buttons for 3 seconds.

10 Thomas, Irvine, CA 92618

USA T (949)-465-0900 F (949)-465-0905

IHH200 Manual 2.5 - Page 15

Parameter

Set-Up Information

Press

To skip to next menu item

Press

To change the 5mV/V gain.

Here the factory gain calibration can be changed to a measured value (see Milli-Volt
Calibration Procedure - back end of manual).

Once the derived value has been entered press

to confirm.

Press

to skip to next menu item

Press

to change the 5mV/V offset.

Here the factory offset value can be changed to a measured value (see Milli-Volt
Calibration Procedure - back end of manual).

Once the derived value has been entered press

to confirm.

THIS CAN ONLY BE SET WHEN USING 50mV/V RANGE

Press

To skip to next menu item

Press

To change the 50mV/V gain.

Here the factory gain calibration can be changed to a measured value (see Milli-Volt
Calibration Procedure - back end of manual).

Once the derived value has been entered press

to confirm.

THIS CAN ONLY BE SET WHEN USING 50mV/V RANGE

Press

to skip to next menu item

Press

to change the 5mV/V offset.

Here the factory offset value can be changed to a measured value (see Milli-Volt
Calibration Procedure - back end of manual).

Once the derived value has been entered press

to confirm.

5.0 gAIn

5.0 OFFS

50 gAIN

50 OFFS
