IHH200 Manual 2.5 - Page 11
Parameter
Set-Up Information
Press
to skip to next menu item
Press
to set a new system zero
This allows the user to introduce a fixed offset to the display value. The
GROSS and
TARED values are then displayed with this offset taken into account.
Values between
-9999999
and
+9999999
can be entered, using the
and
arrows to select a digit and the
and
arrows to increment or decrement the
digits. Press to accept the value and move onto the next parameter.
Set Zero may also be set by pressing
and
at the same time.
Press
To skip to next menu item
Press
To change the update rate
This allows the user to set the display update rate, the options available are the update
rates of the display in Hz. Please note that the 25Hz update is only available in
PEAK or
VALLEY
When you choose to change the update rate you will be prompted whether you want to
select 25Hz, if you do not press
. You will then be prompted to select any of the
other values, which in order, are 10Hz, 3Hz, 1Hz, 0.5Hz. To set the update rate for the
value you want press
.
Press
To skip to next menu item
Press
To set overload alarm
This allows the setting of a visual overload. The value entered is the display value at which
the IHH displays
OUErLOAd
.
Values between
-
9999999
and
+9999999
can be entered, using the
and
arrows to select a digit and the
and
arrows to increment or decrement the
digits. Press
to accept the value and move onto the next parameter.
SEt ZEro
SEt rAtE
SEt OUEr
Configuration Menu
To enter the
CONFIGURATION MENU, press and hold the
and
buttons for 3 seconds.
