FrtE
Fuzzy Logic Rate of Change: Select
0.00
to
99.99
counts/second. For best
initial setting, find the counts/second change of process value near Set Point
1 with output ON 100%. Multiply this value by 3. Set
FrtE
to this
calculated value.
PEA
The Peak feature stores the highest input the control has measured since
the last reset or Power On. At Power On
PEA
is reset to the present input.
To manually reset the value
PEA
must be in the lower display. Press the
ENTER key to reset.
PEA
will be reset and display the present input value.
UAL
The Valley feature stores the lowest input the Instrument has measured
since the last reset or Power On. At Power On
UAL
is reset to the present
input. To manually reset the value
UAL
must be in the lower display. Press
the ENTER key.
UAL
will be reset and display the present input value.
Pct0
Percent Output Feature: Select
0n
or
0FF
.
0n
When selected
0n
, the HOME lower display will indicate the output
of the controller in percent. An “
o
” will appear in the right hand side
of the lower display to indicate percent output for SP1. An “ ” will
appear on the right hand corner of the lower display to represent
percent output for SP2, if the control is so equipped. The display
will alternate between these values.
0FF
Percent Output display is disabled.
Pro9
Ramp/Soak Feature (16A3):
Select
0n
or
0FF
.
0n
Allows Programmed Ramp/Soak function to be started by the
Run/Hold key on the control front panel.
0FF
T
urns Ramp/Soak function
0FF
and resets program to
beginning.
PSEt
Programmer function set (16A3):
Select
0n
or
0FF
.
0FF
Skip Ramp/Soak Programming. Go to next Secondary Menu
Item,
1nPC
on the next page.
0n
Enable Ramp/Soak Programming.
StAt
Programmer Status Display in the Primary Menu when Prog (above) is
On (16A3):
Select
0n
or
0FF
.
0FF
The Primary Menu operates as normal.
0n
The Primary Menu is altered to have the following items
inserted before the SP1 menu item:
####
ti
time remaining in active segment
#### ##
ti
total time in active segment
#### ##
SP
segment target set point
