0ut MENU SELECTIONS
PRIMARY MENU
Press INDEX to advance to the next menu item. Press UP ARROW or
DOWN ARROW to change the value in the display. Press ENTER to
retain the value. If StAt, (Secondary Menu [16A3]), is 0n , the three program status
menu items shown on Page 14 will precede the folowing.
SP1 Set Point 1 Adjust, Control Point 1.
SP2 Set Point 2 Adjust (if equipped), Control Point 2.
SECONDARY MENU
Hold UP ARROW & ENTER. Press INDEX to advance to the next
menu item. Press UP ARROW or DOWN ARROW to change the value
in the display. Press ENTER to retain the value.
A1Lo Alarm 1 Low: The Low Alarm point is usually set below the Set Point. May
not appear depending on
AL1 setting in Secure Menu.
A1Hi Alarm 1 High: The High Alarm Point is usually set above the Set Point. May
not appear depending on
AL1 setting in Secure Menu.
