Badger Meter M-Series M1000 - Manual (Page 32)

SPECIFICATIONS
Flow Range 0 .03…12 m/s
Accuracy ± 0 .3% for velocities greater than 1 .64 ft/sec, ± 0 .0065 ft/sec for velocities less than 1 .64 ft/sec
Conductivity Min . 5 µS/cm (20 µS/cm for demineralized water)
Fluid Temperature With Remote AmplifierE:
PTFE 302° F (150° C),
Hard rubber 178° F (80° C)
With Meter-Mounted AmplifierE:
PTFE 212° F (100° C),
Hard rubber 178° F (80° C)
Ambient Temperature –4…140° F (–20…60° C)
Flow Direction Uni-directional or bi-directional
Analog Output 0/4…20 mA / 0…10 mA, flow direction is displayed on a separate status output
Pulse Output 2 open collectors, passive 32V DC, 0…100 Hz 100 mA, 100…10,000 Hz 20 mA, optional active
Frequency Output Max . 10 kHz (open collector)
Communication RS232, RS422, RS485 Modbus RTU
Empty Pipe Detection Field-tunable for optimum performance based on specific application
Min-Max Flow Alarm Programmable outputs 1…100% of flow
Low Flow Cutoff Programmable 0…10% of maximum flow
Galvanic Separation Functional 50 volts
Pulse Width Programmable 5…500 ms
Coil Power Pulsed DC
Repeatability 0 .1%
Sampling Rate Programmable from 1 to 63 seconds . Standard sampling period is 15 seconds
Display Two lines x 15 characters (7 on top + 8 on bottom), LCD display
Programming 3 external buttons
Units of Measure Gallons, ounces, MGD, liters, cubic meters, cubic feet, imperial gallon, barrel, hectoliter and
acre feet
Power Supply 92…275V AC (50 / 60 Hz), <10 VA optional 9…36V DC
Amplifier Housing Powder-coated aluminium die cast
Detector Housing Carbon steel
Linear Materials Hard Rubber, PFA, PTFE
Electrodes Materials Standard: Hastelloy C
Optional Grounding Rings Stainless steel
Mounting Detector-mount or remote wall mount
NSF Listed Models with hard rubber liner 4" size and up; PTFE liner, all sizes, listing in process
Cable Insertion 2 x M 20
Process Connection Flange: DIN, ANSI, JIS, AWWA
Nominal Pressure Up to 232 psi (16 bar)
Protection Class Standard: NEMA 4X (IP66); Optional: NEMA 6P (IP67)
