Password
Password protection prevents unauthorized users from changing programming information . Initially the password is set to all
zeros . Its displayed name is PASSWORD and is viewed or changed using the Numeric Value Entry Procedure .
Restore Defaults
This feature allows you to restore factory calibration data . Its displayed name is RES DFLT . To restore factory calibration data,
select YES, then press ENTER .
Advanced Programming Descriptions
Advanced programming allows the user access to re-configure the analog output . Calibration of the analog output is preset
at the factory, but can be changed to customize calibration for your installation .
To access the Advanced Programming Options, press and hold MENU for approximately 3 seconds until DISPLAY is viewed on
the display panel . The programming menus will begin with display mode DISPLAY and continue as described above through
output mode OUT MODE .
After output mode has been entered, Advanced Programming starts with the following:
Calibration of Analog Output
This selection allows access to the calibration and testing of the analog output signal .
To test or change the analog output calibration, it is first necessary to change the default setting for CAL OUT? from NO to YES .
OTEE: N Setup prompts and descriptors for configuring and calibrating the analog output will correspond to the output
mode selected . Refer to the Flow Chart .
1 . At the CAL OUT? prompt press ENTER . NO will display .
2 . To change to YES, press either arrow key .
3 . The analog output will go to its minimum output level . A numeric value between 0-4000 will display . This is an internal
number used to drive the analog output .
4 . To increase the analog output signal level, press . To decrease the analog output signal level, press .
5 . Press ENTER to store the setting .
6 . The analog output will go to its maximum output level . A numeric value between 0-4000 will display . This is an internal
number used to drive the analog output .
7 . To increase the analog output signal level, press . To decrease the analog output signal level, press .
8 . Press ENTER to store the setting .
9 . The unit will advance to the analog output test mode . The analog output will go to its minimum output level . A numeric
value of 0 will display . For test purposes, the analog output signal can be run up or down in increments of 1 milliamp or 1
volt, depending on the OUT MODE selected .
10 . To increase the analog output signal level, press . To decrease the analog output signal level, press .
11 . Press ENTER to exit the analog calibration mode .
12 . The unit automatically advances to the PASSWORD feature .
Password
Password protection prevents unauthorized users from changing programming information . Initially the password is set to all
zeros . Its displayed name is PASSWORD and is viewed or changed using the Numeric Value Entry Procedure f .
Restore Defaults
This feature allows you to restore factory calibration data . Its displayed name is RES DFLT . To restore factory calibration data,
select YES, then press ENTER .
MR Flow Transmitter
Page 16 November 2013
