Numeric Value Entry Procedure
OTEE: N If you are already in PROGRAM mode and the desired selection is displayed, proceed to step 3 below . If you are in
PROGRAM mode and the desired selection is not displayed, press or and repeat pressing until the desired
selection appears . Proceed to step 3 .
1 . Press MENU . PROGRAM appears in the lower left-hand corner and DISPLAY appears .
2 . Press or
to move to the desired selection . The current numeric value for this selection appears in the upper section
of the display .
3 . If the current displayed value is desired, press ENTER . The left most programmable number begins to flash . Press ENTER
again to confirm and keep the current setting . The unit will automatically advance .
4 . If the current selection must change, press ENTER . The left most programmable number begins to flash . Use to scroll
through the digits 0-9 and change the flashing digit to the desired value . Use to move the active digit to the right .
Continue using the and until all desired digits are selected .
5 . Press ENTER to confirm your selection . The unit will automatically advance .
6 . To exit programming mode, press MENU . The display will change to RUN mode .
Programming Flow Chart
See the programming flow charts in “Application Information, Liquid” on page 19 for the menu structure of the MR flow
transmitter and the available configuration selections .
Basic Programming Descriptions
Display Mode
The meter can display RATE (flow rate) or TOTAL (total accumulated flow) or alternate between BOTH rate and total . Its
displayed name is DISPLAY and is viewed or changed using the List Item Selection Procedure .
Rate Units of Measure
The meter allows the selection of many common rate units . Its displayed name is RATE UNT and is viewed or changed using
the List Item Selection Procedure .
Rate (Time) Interval
The meter allows selection of several intervals based on time . Its displayed name is RATE INT and is viewed or changed using
the List Item Selection Procedure .
Total Units of Measure
If the total flow is being displayed, the units for the total must first be chosen . The monitor allows the choice of many common
totalization units . Its displayed name is TOTL UNT and is viewed or changed using the List Item Selection Procedure .
Total Display Multiplier
The meter has the ability to accumulate the flow total in multiples of ten . For example, if the most desirable totalization unit
is 1000 gallons, the monitor can easily be set up for this requirement . Once back in RUN mode, every time the total display
increments by one digit the actual total would be an additional 1000 gallons . At 1000 total gallons the total display would
read 1, at 3000 gallons the total display would read 3 . This feature allows the unit to accumulate totals that would exceed the
8-digit display capacity . Table 2 lists the available selection choices . Its displayed name is TOTL EXP and is viewed or changed
using the List Item Selection Procedure .
Exponent Totalizer Multiplier
E-2 x 0 .01 (÷100)
E-1 x 0 .1 (÷100)
E0 x 1 (no multiplier)
E1 x 10
E2 x 100
E3 x 1000
E4 x 10,000
E5 x 100,000
E6 x 1,000,000
Table 1: Total flow units
