ORION® Fixed Network (SE) II Network Gateway Transceiver
Cables & Connectors
Remote antenna installations only –
Antenna cables and connectors are not included and are to be supplied by the professional installation contractor.
Exact parts specified in Badger Meter installation documentation must be used. Substitutions are not allowed.
Confirm parts used by completing table below.
TX/RX Antenna Left TX/RX Antenna Right Backhaul Antenna
Cable Part Number
Cable Length
Connector Part
Number
Flex Cable Kit Used?  Yes  No  Yes  No  Yes  No
VSWR Measurement
Connection
Waterproofing
Method
Grounding Method
Lightning Arrestor
(manufacturer and
model/part number)
Confirmation Photographs
All installations – Photographs of the installation are required as outlined. Confirm photos taken by completing table.
Installation
Pictures
 Ground level view of antenna assembly
 Antenna cable connections (provide all)
 Other antennas in proximity
 East-facing line-of-sight from antenna
assembly
 West-facing line-of-sight from antenna
assembly
 North-facing line-of-sight from antenna
assembly
 South-facing line-of-sight from antenna
assembly
 Installed gateway enclosure and power
source
 Potential obstructions
 Lightning arrestor with ground
connections
 Other
_________________________________
 Other
_________________________________
 Other
_________________________________
Badger Meter ORION Fixed Network II Gateway Installation Form
Page 44 March 2014
