ORION® Fixed Network (SE) II Network Gateway Transceiver
CDMT, GPRS or LTN with 120V TC Power Source
Configurations for a 120V AC grounded outlet with CDMA, GPRS and LAN are shown here .
CDMT or GPRS Connection with 120V TC Power Source
AC to DC Power Supply with
308 In-line Connector End and
Power Cord (supplied)
120VAC
Grounded Outlet
(customer
supplied)
Power Supply Cable with
308 In-line Connector
ORION SE Power Cable with
308 In-line Connector
(supplied)
Figure 16: CDMA or GPRS connection with AC power source (*Shown with NEMA 4 enclosure)
*An enclosure may be recommended but is not included . If NEMA 4 enclosure or equivalent is required, as in an outdoor
installation, the minimum enclosure size is 12 inch x 10 inch x 6 inch (H x W x D) .
