Water Strainer Pressure Drops
Wa
te
rs
id
e
Pre
s
s
ure
Drop
(k
Pa
)
0
2
4
6
8
10
12
14
25 35 45 55 65 75
6"
8"
Water flow (l/s)
The above curves relate to the strainer size (inches). Data based upon the filters being clean.
