Airedale OptiChill FreeCool 500kW - 1365kW - Manual (Page 77)

Chillers OptiChill Freecool
Chillers
77
Technical Manual : 7197700 v1.2.0 02_2013
Electrical Data Regular Quiet Continued
10 11 12
Notes Units OFC107R18-99HL5 OFC078R20-66ML1 OFC084R20-76HL2
Unit Data
Nominal Run Amps (1) A 610 446 491
Maximum Start Amps A 1149 702 925
Recommended Mains Fuse Size A 750 560 630
Mains Supply VAC 400 V 3 PH 50 Hz 400 V 3 PH 50 Hz 400 V 3 PH 50 Hz
Max Mains Incoming Cable Size mm² Direct to Bus Bar Direct to Bus Bar Direct to Bus Bar
Recommended Permanent Fuse Size A 16 16 16
Permanent Supply VAC 230 V 1 PH 50 Hz 230 V 1 PH 50 Hz 230 V 1 PH 50 Hz
Max Permanent Incoming Cable Size mm² 4 mm² terminals 4 mm² terminals 4 mm² terminals
Control Circuit VAC 24V/230VAC 24V/230VAC 24V/230VAC
Evaporator
Trace Heater Rating W 250 250 250
External Trace Heating
Available (fitted by others) W 500 500 500
Condenser Fan - Per Fan (AC)
Quantity 18 20 20
Full Load Amps A 4.3 4.3 4.3
Locked Rotor Amps A 15 15 15
Motor Rating kW 2 2 2
Condenser Fan - Per Fan (EC)
Quantity 18 20 20
Full Load Amps A 3.9 3.9 3.9
Locked Rotor Amps A N/A N/A N/A
Motor Rating kW 2.56 2.56 2.56
Condenser Fan - Per Fan (HAEC)
Quantity 18 20 20
Full Load Amps A 4.5 4.5 4.5
Locked Rotor Amps A N/A N/A N/A
Motor Rating kW 2.86 2.86 2.86
Compressor - Per Compressor
Quantity 1 + 1 1 + 1 1 + 1
Nominal Run Amps A 266.2 / 266.2 179.9 / 179.9 216.3 / 188.9
Motor Rating kW 152.7 / 152.7 105.0 / 105.0 122.5 / 105.0
Sump Heater Rating W 300 300 300
Start Amps (2) A 805 / 805 436 / 436 650 / 586
Type Of Start Star - Delta Star - Delta Star - Delta
OPTIONAL EXTRAS
Low Ambient Kit
Recommended Permanent Fuse Size A 32 32 32
Permanent Supply VAC 230 V 1 PH 50 Hz 230 V 1 PH 50 Hz 230 V 1 PH 50 Hz
Max Permanent Incoming Cable Size mm² 4 mm² terminals 4 mm² terminals 4 mm² terminals
Power Factor Correction
Unit Nominal Run Amps (1) A 541 405 432
Maximum Start Amps A 1114 682 896
Compressor Nominal Run Amps A 232.0 / 232.0 159.5 / 159.5 186.1 / 159.5
Recommended Mains Fuse Size A 750 560 630
Standard Head Pump (Single or Run/Standby)
Unit Nominal Run Amps A 631 461 506
Recommended Mains Fuse Size A 800 560 630
Pump Full Load Amps A 21.2 14.8 14.8
Motor Rating kW 11 7.5 7.5
Larger Head Pump (Single or Run/Standby)
Unit Nominal Run Amps A 638 461 506
Recommended Mains Fuse Size A 800 560 630
Pump Full Load Amps A 28.5 14.8 14.8
Motor Rating kW 15 7.5 7.5
Standard Head Inverter Pump (Single or Run/Standby)
Unit Nominal Run Amps A 631 461 506
Recommended Mains Fuse Size A 800 560 630
Pump Full Load Amps A 21.2 14.8 14.8
Motor Rating kW 11 7.5 7.5
Larger Head Inverter Pump (Single or Run/Standby)
Unit Nominal Run Amps A 638 461 506
Recommended Mains Fuse Size A 800 560 630
Pump Full Load Amps A 28.5 14.8 14.8
Motor Rating kW 15 7.5 7.5
(1) Based at 5.0 Evaporating, 50 Condensing, AC Standard Fans.
(2) Starting amps refers to the Star ( Ү) connection only.
